Description
Key Features:
✔ Selectable Wattage Options:
• 2FT – 20W / 24W / 28W
• 4FT – 22W / 28W / 36W / 44W
• 8FT – 48W / 68W / 90W
✔ Adjustable Color Temperature (CCT): 3500K / 4000K / 5000K
✔ High Luminous Efficacy: Up to 138.98 lm/W
✔ Durable Construction: 22-gauge steel housing with matte white finish & frosted PMMA lens
✔ Optical Performance: Seoul 2835 LED chips with 120° beam angle
✔ Long Lifespan: Rated for 50,000 hours
✔ 0–10V Dimming Standard
✔ Linkable Design:
• 4FT – Connect up to 20 fixtures
• 8FT – Connect up to 10 fixtures
✔ Versatile Mounting Options: Hanging chain, surface mount, or J-adaptor
✔ Temperature Rated: Operates from -4°F to 122°F (-20°C to 50°C)
✔ IP20 Rated: Ideal for dry, indoor applications
✔ Optional Add-ons: Emergency battery backup and motion sensor (4FT models only)
✔ TAA-Compliant Options Available
Product Specifications
| Model | Wattage Selectable | CCT Selectable | Max Lumen Output | Efficacy | Voltage | CRI | Power Factor | THD |
|---|---|---|---|---|---|---|---|---|
| 2FT | 20W / 24W / 28W | 3500K / 4000K / 5000K | Up to 3,640 LM | 130 lm/W | 120-277V | 80 | 0.9 | ≤10% |
| 4FT | 22W / 28W / 36W / 44W | 3500K / 4000K / 5000K | Up to 5,727 LM | 130 lm/W | 120-277V | 80–84 | 0.9739 | ≤6.82% |
| 8FT | 48W / 68W / 90W | 3500K / 4000K / 5000K | Up to 12,062 LM | 138.98 lm/W | 120-277V | 84.1 | 0.9784 | ≤13.42% |
Applications:
✔ Warehouses & Distribution Centers – Bright, consistent lighting for large spaces
✔ Factories & Manufacturing Floors – Energy-efficient and durable illumination
✔ Shopping Malls & Retail Spaces – Clean and uniform light for product visibility
✔ Parking Garages & Auto Dealerships – Long-life fixtures for safety and reliability
✔ Supermarkets & Stadiums – Custom light levels with selectable wattage and color
