Description
Key Features
-
High Efficiency: Delivers 1,600 lumens using only 9.5W, achieving an impressive 168 lm/W.
-
Two Color Options: Available in 4000K Neutral White or 5000K Daylight White for clean, bright illumination.
-
Wide Light Coverage: 270° beam angle ensures broad, even distribution in any space.
-
Durable Design: Built with shatterproof glass, PET film, and a sturdy PC cap for long-lasting performance.
-
Versatile Installation: Works as Type B single or double ended, compatible with shunted & non-shunted sockets.
-
Long Lifespan: Rated for 50,000 hours with no mercury or UV output.
-
Commercial Ready: Ideal replacement for 32W fluorescent T8 tubes; suitable for offices, hospitals, hotels, schools, and more.
-
Reliable Performance: 120–277V, power factor 0.9, THD 20%, and built with quality 2835 LED chips.
-
NSF Rated: Certified for Splash Zone & Non-Food Zone environments.
| Attribute | LOC-4FTT8B-9.5W40K (4000K) | LOC-4FTT8B-9.5W50K (5000K) |
|---|---|---|
| Wattage | 9.5W | 9.5W |
| Lumens | 1,600 lm | 1,600 lm |
| Efficacy | 168 lm/W | 168 lm/W |
| Color Temperature | 4000K (Neutral White) | 5000K (Daylight White) |
| CRI | 82 | 82 |
| Beam Angle | 270° | 270° |
| Input Voltage | 120–277V | 120–277V |
| Power Factor | 0.9 | 0.9 |
| THD | 20% | 20% |
| Construction | Shatterproof glass with PET film & PC cap | Shatterproof glass with PET film & PC cap |
| LED Chip Type | 2835 LED chips | 2835 LED chips |
| Lens | PET-coated shatterproof | PET-coated shatterproof |
| Installation | Type B single or double ended | Type B single or double ended |
| Socket Compatibility | Works with shunted & non-shunted sockets | Works with shunted & non-shunted sockets |
| Operating Temperature | -20°C to 45°C (-4°F to 113°F) | -20°C to 45°C (-4°F to 113°F) |
| Rated Lifetime | 50,000 hours | 50,000 hours |
| Mercury / UV | None | None |
| Enclosed Fixture Rated | No – not for enclosed fixtures | No – not for enclosed fixtures |
| Ingress Protection | IP20 | IP20 |
| NSF Rating | NSF Splash Zone & Non-Food Zone | NSF Splash Zone & Non-Food Zone |
| DLC Listing | S-0UMPBG | S-4GN1L9 |
| Replaces | 32W Fluorescent T8 | 32W Fluorescent T8 |
| Weight | 0.43 lbs | 0.43 lbs |
| Warranty | 5-year limited | 5-year limited |
| Optional Accessory | LOC-EMDR-25WHV Emergency Battery | LOC-EMDR-25WHV Emergency Battery |
| Suitable Applications | Offices, hospitals, commercial buildings, hotels, schools, factories, supermarkets, airports | Same applications |
