Description
Key Features:
✔ Adjustable Wattage & CCT – Selectable power levels and color temperatures (3500K, 4000K, 5000K) to match your lighting needs.
✔ High-Efficiency LED Chips – Samsung 2835 LED chips provide bright, glare-free illumination with a frosted lens and a 110° beam angle.
✔ Long-Lasting Performance – With a 50,000-hour lifespan and a 5-year limited warranty, these fixtures deliver reliable and maintenance-free lighting.
✔ Durable Construction – Built with a 22-gauge metal housing and matte white finish, ensuring durability and longevity.
✔ Flexible Installation – Supports suspension or surface mounting, with optional metal joiner brackets for linking multiple units together.
✔ 0-10V Dimming – Standard dimming capability allows for energy savings and customizable brightness.
✔ Wide Voltage Range – Works with 120-277V input, making it suitable for various applications.
Performance Specifications:
LOC-4FTWA-MW(30/40/50/60)MCCT(35/40/50)
🔹 Wattage Options: 30W, 40W, 50W, 60W
🔹 Lumens Output: 3,936LM - 7,872LM
🔹 Efficacy: 131.2 lm/W
🔹 CRI: 82
🔹 Ideal for Low-Bay, Stairwell, and Direct Linear Applications
LOC-4FTWA-MW(22/28/34/44)MCCT(35/40/50)D
🔹 Wattage Options: 22W, 28W, 34W, 44W
🔹 Lumens Output: 3,031LM - 6,063LM
🔹 Efficacy: 137.8 lm/W
🔹 CRI: 80
🔹 Linkable up to 10 units
LEDONE 4FT Multi-Wattage, Multi-CCT Wrap Around Light Comparison
| Feature | LOC-4FTWA-MW(30/40/50/60)MCCT(35/40/50) | LOC-4FTWA-MW(22/28/34/44)MCCT(35/40/50)D |
|---|---|---|
| Wattage Options | 30W / 40W / 50W / 60W | 22W / 28W / 34W / 44W |
| Selectable CCT | 3500K / 4000K / 5000K | 3500K / 4000K / 5000K |
| Lumen Output | 3,936LM - 7,872LM | 3,031LM - 6,063LM |
| Efficacy | 131.2 lm/W | 137.8 lm/W |
| Input Voltage | 120-277V | 120-277V |
| CRI (Color Rendering Index) | 82 | 80 |
| Beam Angle | 110° | 110° |
| Dimming | 0-10V Dimming Standard | 0-10V Dimming Standard |
| Construction | 22-gauge metal housing with matte white finish | 22-gauge metal housing with matte white finish |
| Lens Type | Frosted PMMA Cover | Frosted PMMA Cover |
| Mounting Options | Suspension or Surface Mount | Suspension or Surface Mount |
| Linkability | - | Can link up to 10 units |
| Lifespan | 50,000 hours | 50,000 hours |
| IP Rating | IP20 | IP20 |
| Warranty | 5-Year Limited Warranty | 5-Year Limited Warranty |
| Ideal Applications | Warehouses, Retail Spaces, Corridors, Supermarkets, Parking Areas | Warehouses, Retail Spaces, Corridors, Supermarkets, Parking Areas |
| DLC Certification | Yes (Low-Bay, Direct Linear, Stairwell) | Yes |
| Optional Accessories | Emergency Driver | Emergency Driver |
Ideal Applications:
✅ Warehouses
✅ Supermarkets
✅ Corridors & Stairwells
✅ Retail Spaces
✅ Parking Areas
