Description
The LED LOC-RGAL Area Light Series delivers powerful, energy-efficient outdoor lighting designed for demanding commercial and industrial applications. Built with a durable bronze die-cast aluminum housing and IP65-rated protection, these fixtures are engineered to withstand harsh weather conditions while providing reliable illumination for parking lots, warehouses, stadiums, factories, and large outdoor spaces.
Featuring a full cut-off design and Type 3 optics, the LOC-RGAL series provides excellent light distribution with reduced glare and improved visibility. Select models offer multi-wattage and multi-CCT adjustability for flexible installation and easier inventory management. Standard 0-10V dimming, optional motion sensors, photocells, and multiple mounting options make these fixtures ideal for both retrofit and new construction projects.
Backed by a 50,000-hour lifespan and a 5-year limited warranty, the LOC-RGAL area light family is a dependable solution for high-output exterior lighting applications.
Spec Sheet
*Mounting Sold Separately*
| Attribute | 150W Max Area Light (No MCCT) | 320W Max Area Light (No MCCT) | 320W Max Area Light w/ MCCT |
|---|---|---|---|
| Product Series | LOC-RGAL Area Light | LOC-RGAL Area Light | LOC-RGAL Area Light |
| Wattage | 150W | 320W | 320W |
| Wattage Selectable | 75W / 100W / 120W / 150W | 160W / 200W / 240W / 320W | 160W / 200W / 240W / 320W |
| Color Temperature | 5000K | 5000K | 3000K / 4000K / 5000K |
| Lumens | Up to 22,500LM | Up to 48,000LM | Up to 46,400LM |
| Efficacy | Up to 150 lm/W | Up to 150 lm/W | Up to 145 lm/W |
| Voltage Options | 120-277V | 120-277V | 120-277V |
| CRI | 70 | 70 | 70 |
| Power Factor | 0.9+ | 0.9+ | 0.9+ |
| THD | ≤20% | ≤20% | ≤20% |
| Beam Angle | 120° | 120° | 120° |
| Lens Type | Type 3 Standard | Type 3 Standard | Type 3 Standard |
| Dimming | 0-10V Standard | 0-10V Standard | 0-10V Standard |
| Surge Protection | 10KV | 10KV | 10KV |
| Housing Material | Bronze Die-Cast Aluminum | Bronze Die-Cast Aluminum | Bronze Die-Cast Aluminum |
| Finish | Corrosion & Rust Resistant | Corrosion & Rust Resistant | Corrosion & Rust Resistant |
| IP Rating | IP65 | IP65 | IP65 |
| Lifespan | 50,000 Hours | 50,000 Hours | 50,000 Hours |
| Operating Temperature | -40°F to 104°F | -40°F to 104°F | -40°F to 104°F |
| HID Replacement | 175W–600W HID | 600W–1000W HID | 600W–1000W HID |
| Mounting Options | Slip Fitter, Arm, Trunnion, U-Bracket | Slip Fitter, Arm, Trunnion, U-Bracket | Slip Fitter, Arm, Trunnion, U-Bracket |
| Weight | 8.25 lbs | 15.25 lbs | 15.25 lbs |
| Warranty | 5-Year Limited Warranty | 5-Year Limited Warranty | 5-Year Limited Warranty |
