| Product Type |
Selectable LED Surface Round Down Light |
| Model |
WSD-RDW182430W347-345K-W |
| Wattage Options |
18W / 24W / 30W |
| Lumen Output |
2,111 / 2,960 / 3,574 Lumens |
| Luminous Efficacy |
>120 lm/W |
| Color Temperature |
3000K / 4000K / 5000K |
| CCT |
3-CCT Selectable |
| CRI |
>80 |
| Input Voltage |
AC 120–347V |
| Beam Angle |
108° |
| LED Type |
2835 |
| Power Factor |
>0.90 |
| Driver Efficiency |
>90% |
| Dimming |
Continuous 1–10V Dimming |
| Life Time |
>50,000 Hours |
| Operating Temperature |
-4°F to 122°F |
| Location Rating |
Damp Location |
| Shell Material |
Aluminum & PC |
| Finish |
White |
| Product Dimensions |
Ø9.85" × 2.09" |
| Net Weight |
2.0 lbs |
| Warranty |
5-Year Limited Warranty |
| Certifications |
UL, Energy Star |
| Mounting Type |
Surface Mount |
| Selectable Power |
18W / 24W / 30W |
| Selectable CCT |
3000K / 4000K / 5000K |
| Emergency Backup |
Optional; Sold Separately |
| Emergency Backup Option |
WSD-EMPK04E27-4W, 4W Emergency Backup Battery LED Driver |
| Control Options |
Emergency, Motion Sensor, Emergency + Motion Sensor |
| Control Accessories |
Microwave Sensor / Microwave Motion Sensor / Remote Controller |
| Factory Setting |
30W / 4000K |
| Applications |
Hallways, Multipurpose Rooms, Underground Parking, Supermarkets, Stores & Other Indoor Applications |
